PP PE Recycling Machine
Functional purpose
Adopting special screw design and different configurations, it is suitable for the regeneration and color mixing granulation of various plastics such as PP, PE, PS, ABS, PVC, etc. The gearbox adopts a high torque design, achieving noise free and smooth operation. The screw and barrel have undergone special hardening treatment, which has the characteristics of wear resistance, good mixing performance, and high yield. The design of vacuum exhaust or ordinary exhaust port can remove moisture and exhaust gas during the production process, making the material more stable and the rubber particles more solid, ensuring excellent product quality.
Plastic granulators are mainly used for processing waste plastic films (industrial packaging films, agricultural films, greenhouse films, beer bags, handbags, etc.), woven bags, agricultural convenience bags, pots, barrels, beverage bottles, furniture, daily necessities, etc. They are suitable for most common waste plastics and are the most widely used and popular plastic recycling processing machinery in the waste plastic recycling industry.
Specification for each equipment
Model |
ZLJ-100 |
ZLJ-120 |
ZLJ-140 |
ZLJ-160 |
capacity |
80-120KG/H |
150-200KG/H |
200-300KG/H |
300-400KG/H |
Raw materials |
HDPE/LDPE/LLDPE OPP/CPP/PP ABS EVA |
|||
Power |
3Phase/380V/50HZ (can be your request) |
|||
Gear box |
173# |
200# |
225# |
280# |
38Cr cast alloy Screw |
Φ100mm length:2000mm |
Φ120mm length:2400mm |
Φ140mm length:2800mm |
Φ160mm length :3200mm |
Driving |
Motor:22KW |
Motor:37KW |
Motor:45KW |
Motor:55KW |
Filter |
Double Screen filter, Hydraulic Change Screen |
|||
Control box |
5 zones |
5 zones |
6 zones |
7 zones |
Cooling system |
Size :2500*400*600mm material :stainless steel(with fan) |
|||
Cutter system |
Hob cutter machine(speed can be control)Diameter :200mm Motor :2.2KW-6P with inverter cut size :3-4MM |
|||
Totally power |
40KW |
60KW |
75KW |
110KW |
FAQ
SEE WISDOM MACHINE HOW TO ENSURE THE QUALITY
● In order to ensure the accuracy of each part, we are equipped with a variety of professional processing equipment and we have accumulated professional processing methods over the past years.
● Each component before assembly needs strict control by inspecting personnel.
● Each assembly is in charge by a master who has working experience for more than 15 years
● After all the equipment are completed, we will connect all the machines and run the full production line for at least 12 hours to ensure the stable running in customers' factory
THE AFTER-SALE SERVICE OF WISDOM MACHINERY
● After finishing the production, we will debug the production line, take photos, videos and send them to customers via mail or instant tools.
● After the commissioning, we will package the equipment by the standard export package for shipment.
●According to the customer's request, we can arrange our engineers to customers' factories to do the installation and training.
● Engineers, sales managers, and after-sales service managers will form an after-sales team, online and offline, to follow the customers' project.
