400-500KGS PE FILM Waste Recycling Machine

Name: 400-500KGS PE FILM Waste Recycling Machine
Brand: WISDOM
SKU: 269300411

Detailed image Functional purpose Adopting special screw design and different configurations, it is suitable for the regeneration and color mixing granulation of various plastics such as PP, PE, PS, ABS, PVC, etc. The gearbox adopts a high torque design, achieving noise free and smooth...

Send Inquiry

Product Introduction

Detailed image

product-897-447

product-896-437

Functional purpose

Adopting special screw design and different configurations, it is suitable for the regeneration and color mixing granulation of various plastics such as PP, PE, PS, ABS, PVC, etc. The gearbox adopts a high torque design, achieving noise free and smooth operation. The screw and barrel have undergone special hardening treatment, which has the characteristics of wear resistance, good mixing performance, and high yield. The design of vacuum exhaust or ordinary exhaust port can remove moisture and exhaust gas during the production process, making the material more stable and the rubber particles more solid, ensuring excellent product quality.

Plastic granulators are mainly used for processing waste plastic films (industrial packaging films, agricultural films, greenhouse films, beer bags, handbags, etc.), woven bags, agricultural convenience bags, pots, barrels, beverage bottles, furniture, daily necessities, etc. They are suitable for most common waste plastics and are the most widely used and popular plastic recycling processing machinery in the waste plastic recycling industry.

Specification for each equipment

Model	ZLJ-100	ZLJ-120	ZLJ-140	ZLJ-160
capacity	80-120KG/H	150-200KG/H	200-300KG/H	300-400KG/H
Raw materials	HDPE/LDPE/LLDPE OPP/CPP/PP ABS EVA
Power	3Phase/380V/50HZ (can be your request)
Gear box	173#	200#	225#	280#
38Cr cast alloy Screw	Φ100mm length:2000mm	Φ120mm length:2400mm	Φ140mm length:2800mm	Φ160mm length :3200mm
Driving	Motor:22KW	Motor:37KW	Motor:45KW	Motor:55KW
Filter	Double Screen filter, Hydraulic Change Screen
Control box	5 zones	5 zones	6 zones	7 zones
Cooling system	Size ：2500400600mm material ：stainless steel(with fan)
Cutter system	Hob cutter machine(speed can be control)Diameter :200mm Motor :2.2KW-6P with inverter cut size ：3-4MM
Totally power	40KW	60KW	75KW	110KW

FAQ

SEE WISDOM MACHINE HOW TO ENSURE THE QUALITY

● In order to ensure the accuracy of each part, we are equipped with a variety of professional processing equipment and we have accumulated professional processing methods over the past years.

● Each component before assembly needs strict control by inspecting personnel.

● Each assembly is in charge by a master who has working experience for more than 15 years

● After all the equipment are completed, we will connect all the machines and run the full production line for at least 12 hours to ensure the stable running in customers' factory

THE AFTER-SALE SERVICE OF WISDOM MACHINERY

● After finishing the production, we will debug the production line, take photos, videos and send them to customers via mail or instant tools.

● After the commissioning, we will package the equipment by the standard export package for shipment.

●According to the customer's request, we can arrange our engineers to customers' factories to do the installation and training.

● Engineers, sales managers, and after-sales service managers will form an after-sales team, online and offline, to follow the customers' project.
