flexo printing machine 6 colour

I.CONTROL PART
1. Main motor frequency control
2. PLC touch screen control the whole machine
3. Deceleration motor carries ink separately

II. UNWINDING PART
1. Single work station
2. 3 inch air shaft hydraulic lift the material
3. Magnetic powder brake auto tension control
4. Auto web guide

III. PRINTING PART
1. Hydraulic lifting and lowing printing plate cylinders auto lifting plate cylinder when the machine is stopped. After that can run ink automatically. When the machine is opening,it will make alarm to start the auto lowering plate printing cylinder.
2. Inking with ceramic anilox with chambered doctor blade (6 pcs)
3. The plate roller gear, adopts special helical gear transmission. Each tooth 5MM, more stable printing effect, and more accurate printing length .

4. ±0.15mm transverse register
5. Adjust inking press and printing pressure press by manual
6. Can print 6+0,5+1,4+2, 3+3,

IV. DRYING PART
1. Adopt with external heating pipe, temperature display, electric current control, centrifugal blower bring the wind

V.REWINDING PART
1. Back to back rewinding/Central winding (according to the material )

2. Pneumatic tension control

3. 2.2kw motor,vector frequency conversion control

4. 3 inch air shaft

5. Hydraulic lowering the material

二,Feature：

1. The frame adopts 75MM thick wall, full casting flat plate, increase the scale and so on to enhance the stability.

2. The printing roller is made of thickened steel bars, with 10 silk thick hard chrome protective layer.

3. The aluminum alloy guide wheel, with hard oxidation, dynamic balance, static balance treatment.

4. High-precision wider synchronous belt drive, low noise while high speed running, low vibration, makes machine more stable.

5.The plate roller gear, adopts special helical gear transmission. Each tooth 5MM, more stable printing effect, and more accurate printing length .

三,Main points:

-Adopts the synchronous belt drive instead of Gear drive;

-Machine running more quite, higher printing precision, good quality;

-Machine more stability;

-High Mechanical speed: 135m/min

-High printing speed: 10-120m/min ( match enclosed chamber doctor blade)

- Single unwind & single rewind

四,Technical Parameter :

五,THE PARTS

Free Spare Parts

七,Machine photo for reference:

machine drive by belt

Single unwind ,Back to back /Center rewinding,Hydraulic lowering the material

Ceramic anilox roller , enclosed chamber doctor blade and ink pump

blower on top and down and blower between each print unit

PLC operate panel and automatic tension controller

Hydraulic lifting and lowing printing plate cylinders
